FOX-DL-8MP
Dual-Lens · Dual-Screen · Solar WiFi Camera
See everything — near and far — simultaneously. The FOX-DL-8MP combines a fixed wide-angle lens with a 355° PTZ rotating lens on a single solar-powered unit. Two lenses. Two screens. Complete coverage. Zero blind spots.
- 8MP (4MP+4MP)
- Dual-Screen View
- 355° PTZ Control
- Solar + 7800mAh
- IP66 Waterproof
- Full-Colour Night Vision
- Spotlight & Siren
- Two-Way Audio
Full Product Details
Every feature, every specification — at a glance.
Key Features
Dual-Lens, Dual-Screen
One fixed wide-angle lens and one PTZ rotating lens running simultaneously — see near and far at the same time.
8MP 4K Resolution
4MP + 4MP combined for ultra-clear footage on both screens. Every detail captured in stunning clarity.
355° Pan & 90° Tilt
Full-scene PTZ control from your phone. Rotate and tilt to cover every angle with zero blind spots.
Solar Powered
Built-in solar panel and 7800mAh rechargeable battery for continuous, wire-free operation all day and night.
Full-Colour Night Vision
Advanced starlight sensors and built-in LED lights deliver clear, vibrant colour footage even in complete darkness.
Spotlight & Siren Alarm
Active deterrence with spotlight activation and instant siren alarm to scare off intruders immediately.
Two-Way Audio
Talk and listen in real time through the built-in speaker and microphone from anywhere in the world.
PIR Motion Detection
Smart PIR detection with 10m / 120° range triggers instant alerts so you never miss a thing.
IP66 Weatherproof
Rated IP66 — built to withstand heavy rain, heat, and extreme outdoor Australian weather conditions.
Remote Monitoring
Full iOS and Android app control. Monitor, replay, and manage your camera from anywhere at any time.
Technical Specifications
| Model | JD-ASH20-PT7404WSU-M |
| Connectivity | WiFi Only — 2.4G, 802.11b/g/n |
| Pixel | 4MP + 4MP (8MP Total) |
| Sensor | 1/3" CMOS |
| Lens | 4mm |
| Resolution | 2304 × 2592 HD |
| Video Stream | Main: 2304×2592 @ 12.5fps / Sub: 800×480 @ 12.5fps |
| Video Compression | H.265 |
| Night Vision Distance | 15 Metres |
| Dual Light Source | 4 White Lights + 4 IR Lights |
| PIR Range | 10m / 120° |
| PTZ | 355° Horizontal / 90° Vertical |
| Battery Capacity | 7800mAh |
| Standby Time | Up to 4–6 Months* |
| Input Power | DC5V |
| Min. Illumination | Color: 0.1 Lux / B/W: 0.01 Lux |
| Audio | AAC G711 — Two-Way Audio |
| Storage | Cloud & SD Card |
| Operating Temp. | -10°C ~ +50°C |
| Operating Humidity | 30% ~ 80% RH |
| Dimensions | 200 × 150 × 120 mm |
| Waterproofing | IP66 |
| Remote Access | iOS & Android App |
* Standby time based on lab data. Actual performance may vary depending on conditions.
Suitable Applications
Built for a variety of real-world surveillance scenarios.
Home Security
24/7 dual-view protection for residential properties.
Business & Warehouse
Wide coverage for commercial premises and storage facilities.
Backyard & Garden
Monitor your outdoor areas day and night with ease.
Doorway & Entry Points
Keep an eye on every entrance with close-up and wide-view simultaneously.
Interested in the FOX-DL-8MP?
Contact us today for pricing, availability, and professional installation across Victoria.
